Description
NEXT-GENERATION
OPEN-BACK CIRCUMAURAL, VENTED FRONT CHAMBER
TRUE-RIBBON R² DUAL-DRIVER
“Make no mistake, MAGNA is not a detuned, compromised version of IMMANIS.
MAGNA (dual-ribbon) is ideal for those seeking authenticity of timbre, scale & proportionality in mid-size and smaller ensembles, regardless of genre. String quartets, piano trios, singer/songwriter, classic jazz and blues, all presented with stunning clarity of space, while kicking like a mule, when the music calls for it.
Light weight and comfortable for many hours of enjoyment, MAGNA does it all with uncompromising audio excellence.”
Danny “Sage” McKinney
We welcome your call/email to learn more about these very special instruments of personal audio.
MAGNA PACKAGE SET
Headphones: MAGNA (dual-ribbon)
Ribbon Current-Drive Interface / Stand: RCD Interface 32 Ohm (8 Ohm & Viva by request)
Cable (Amplifier to RCD Interface): RCD-XLR (XLR4 to XLR4) 1.5m
Cable (Headphones to RCD Interface): Satis Copper 1.8m
Case: Waterproof Hard Molded Plastic / Foam Lined
MOTOR Specifications
Configuration
Complimentary Tuned Dual Ribbon
Ribbon Type
Corrugated Pure Aluminum (True-Ribbon) with Viscodamp™ “Silent Metal” Viscosity Dampening
Surface Area
16.8 cm² (2.6 in²)
Excursion
+/- 4mm (0.157 in)
Maximum SPL
115dB
Impedance
0.038Ω
Impediance with Specialized HP Cable
0.27Ω
Note: Cable Connector
Female XLR 4-pin. Gender not compatible with Standard Amplifier Output Connector. Due to pin-out arrangement and 0.3 Ohm load, do not make adapters and plug it directly to Amplifiers, as that will destroy both the Amp and the Headphones. Connect only to RCDI-32, RCDI-8, RCDI-Viva or to specialized Direct-Drive Amplifiers for RAAL Headphones (HSA-1a/b/c, VM-1a, Jotunheim R).
